AUDIOVISUAL / NOVASTAR
TU20 Pro
Playback control for indoor LED, presentations and screen mirroring.
TU20 Pro
An Android playback processor for indoor LED screens, combining HDMI sources, USB media and wireless screen mirroring for meetings and presentations.
Specifications
| Pixel capacity | 3,900,000 pixels (scaling); 2,880,000 pixels (pixel-to-pixel) |
|---|---|
| Maximum width | 4,096 pixels |
| Maximum height | 1,920 pixels |
| LED Ethernet outputs | 6 × Gigabit RJ45 |
| Inputs | 2 × HDMI 1.3; 3 × USB 2.0 |
| Other outputs | 1 × HDMI; 1 × 3.5 mm audio; 1 × SPDIF |
| Processor | Quad-core ARM A55 · 1.8 GHz |
| Memory / storage | 4 GB RAM / 32 GB storage |
| Operating system | Android 11 |
| Control | Remote / ViPlex Handy / wireless screen mirroring |
Maximum width and height are separate limits; the total pixel capacity also applies. Features depend on firmware and the connected receiving cards.
Matched to your screen.
Share the total pixel resolution, required inputs and application. We check the version and connections that suit your project.
For your quotation
- Screen width, height and pixel pitch
- Sources and required inputs
- Live video, signage or presentations
- Quantity and required delivery date
